ZJ105W - 10 Ton Wheeled Excavator

Name: ZJ105W - 10 Ton Wheeled Excavator
Brand: GLOBALMACHEX
Availability: InStock
Rating: 5 (1 reviews)

ZJ105W Multi-functional Wheeled Excavator

1. Mobility: The wheeled chassis design allows the ZJ105W to travel quickly on roads, eliminating the need for trailers and enabling rapid movement between different construction sites, thus improving work efficiency.

2. Multi-functionality: It can be equipped with various attachments, such as buckets, grapples, and breakers, allowing one machine to perform multiple tasks including excavation, loading, demolition, and breaking, broadening its applicability.

3. Wide range of applications: Suitable for municipal construction, road engineering, pipeline construction, landscaping projects, and other fields, especially on paved roads or in situations requiring frequent movement, making it more suitable than tracked excavators.

$30000.00 - 50000.00

Send Message Contact Supplier

Shandong Zhongjue Heavy Industry Co., Ltd.

View Supplier

Established 2015

Area 20000m²

Foreign Trade Experience 10 years

Export Countries More than 100 countries

Annual Sales Over 130 million US dollars

Main Products Full hydraulic wheel excavators, small and medium-sized crawler excavators, skid steer loaders, CNC rebar processing equipment, dredging and demolition robots, customized excavator modifications

Application Fields Landscaping, agricultural production, municipal engineering, water conservancy construction, civil construction

Certifications ISO9001, ISO14001, EU CE Certification

Main Export Markets Central Asia, Russia, Southeast Asia, Africa, Europe, America

Details

Specifications

Item	Parameter	Item	Parameter
Model	ZJ105W	Max. Digging Reach	7500 mm
Operating Weight	9600 kg	Max. Ground-Level Digging Reach	7318 mm
Bucket Capacity	0.31 m³	Max. Digging Depth	3652 mm
Engine Model	Yuchai YC4FA85	Max. Vertical Digging Depth	3200 mm
Power	62.5 kW / 2200 rpm	Min. Swing Radius	2431 mm
Fuel Tank Capacity	147 L	Tail Swing Radius	2212 mm
Travel Speed	30 km/h	Max. Height at Min. Swing Radius	5866 mm
Swing Speed	12 r/min	Counterweight Ground Clearance	1094 mm
Gradeability	38°	Min. Ground Clearance	283 mm
Bucket Digging Force	39 kN	Wheelbase	2500 mm
Arm Digging Force	30 kN	Tire Width	510 mm
Hydraulic Pump Model	Load Sensing Variable Piston Pump (Electronic Control)	Arm Length	2200 mm
Max. Flow Rate	209 L/min	Boom Length	4000 mm
Working Pressure	24.5 MPa	Max. Attachment Dumping Height	6240 mm
Hydraulic Tank Capacity	140 L	Max. Attachment Lifting Capacity	800 kg
Transport Length	7153 mm	Max. Attachment Opening Size	1300 mm
Transport Height	2940 mm	Min. Attachment Opening Size	102 mm
Transport Width	2200 mm	Max. Attachment Lifting Height	8127 mm
Max. Digging Height	7931 mm	Max. Attachment Grabbing Height	7927 mm
Max. Dumping Height	5903 mm

Model

ZJ105W

Engine

Yuchai YC4FA85

Power

62.5 kW / 2200 rpm

Weight

9600 kg

Description

Item	Parameter	Item	Parameter
Model	ZJ105W	Max. Digging Reach	7500 mm
Operating Weight	9600 kg	Max. Ground-Level Digging Reach	7318 mm
Bucket Capacity	0.31 m³	Max. Digging Depth	3652 mm
Engine Model	Yuchai YC4FA85	Max. Vertical Digging Depth	3200 mm
Power	62.5 kW / 2200 rpm	Min. Swing Radius	2431 mm
Fuel Tank Capacity	147 L	Tail Swing Radius	2212 mm
Travel Speed	30 km/h	Max. Height at Min. Swing Radius	5866 mm
Swing Speed	12 r/min	Counterweight Ground Clearance	1094 mm
Gradeability	38°	Min. Ground Clearance	283 mm
Bucket Digging Force	39 kN	Wheelbase	2500 mm
Arm Digging Force	30 kN	Tire Width	510 mm
Hydraulic Pump Model	Load Sensing Variable Piston Pump (Electronic Control)	Arm Length	2200 mm
Max. Flow Rate	209 L/min	Boom Length	4000 mm
Working Pressure	24.5 MPa	Max. Attachment Dumping Height	6240 mm
Hydraulic Tank Capacity	140 L	Max. Attachment Lifting Capacity	800 kg
Transport Length	7153 mm	Max. Attachment Opening Size	1300 mm
Transport Height	2940 mm	Min. Attachment Opening Size	102 mm
Transport Width	2200 mm	Max. Attachment Lifting Height	8127 mm
Max. Digging Height	7931 mm	Max. Attachment Grabbing Height	7927 mm
Max. Dumping Height	5903 mm
