T-type Canal Forming Machine

T-type canal forming machine is special cast-in-place slipform equipment for farmland irrigation, municipal drainage and water conservancy projects. It completes one-time extrusion & vibration forming of T-type drainage ditch on site. No prefabricated blocks or manual masonry needed. Equipped with diesel power, automatic hopper feeding, electric control full-automatic system. The formed canal is dense, smooth, anti-seepage and durable, with much higher construction efficiency than traditional manual canal construction.
$6200.00
Send Message Contact Supplier
Play

Shandong Yahui Mechanical Equipment Manufacturing Co., Ltd.

View Supplier
Registration Date August 2, 2019
Number of Employees 50-100
Factory Area 6,000 m²
Annual Sales 30 Million RMB
Main Products Canal Forming Machine, Curb Stone Forming Machine, Paver, Crawler Carrier, Crawler Lift Platform, Crawler Chassis, Underwater Dredging Robot, Crawler Fire Fighting Robot, Lawn Mower, Skid Steer Loader, Crawler Transporter
Target Markets Belt & Road Countries, Europe, America & Global Markets
Details
Specifications
This machine is full-automatic T-type canal cast-in-place slipform equipment. Equipped with 24kw diesel generator set as main power, matched with 3kw hopper automatic feeding system. Standard equipped with complete accessories: special T-type canal mould, bucket feeding device, intelligent electric control box, joint cutting knife. Integrated operation of automatic feeding, vibrating, forming and joint cutting. Special for farmland irrigation canals, drainage canals and T-type anti-seepage canals. Sturdy structure, excellent anti-seepage effect and long service life of formed canal.
Diesel Generator Power
24kw
Hopper Winch Power
3kw
Overall Machine Size
2300×2200×1500mm
Model
T-type Canal Forming Machine
Standard Configuration
1 Set T-type Mould + 1 Set Bucket + 1 Set Electric Control Box + 1 Set Cutting Knife
Bucket Size
2600×700×700mm
Machine Weight
2.2T
Working Mode
On-site Cast-in-place Slipform One-step Forming T-type Canal
  • T-type Canal Forming Machine
  • T-type Canal Forming Machine
  • T-type Canal Forming Machine
  • T-type Canal Forming Machine
  • T-type Canal Forming Machine
  • T-type Canal Forming Machine

Description

This machine is full-automatic T-type canal cast-in-place slipform equipment. Equipped with 24kw diesel generator set as main power, matched with 3kw hopper automatic feeding system. Standard equipped with complete accessories: special T-type canal mould, bucket feeding device, intelligent electric control box, joint cutting knife. Integrated operation of automatic feeding, vibrating, forming and joint cutting. Special for farmland irrigation canals, drainage canals and T-type anti-seepage canals. Sturdy structure, excellent anti-seepage effect and long service life of formed canal.
