HXPS Series Aquaculture Protein Separator High-Efficiency Foam Fractionator

Name: HXPS Series Aquaculture Protein Separator High-Efficiency Foam Fractionator
Brand: GLOBALMACHEX
Availability: InStock
Rating: 5 (1 reviews)

HXPS series protein separator uses Venturi jet technology to efficiently remove dissolved proteins and fine particles. Ozone-compatible and zero-corrosion, suitable for both saltwater and freshwater systems, widely used in industrial aquaculture, aquariums and industrial recirculating water treatment.

$4575.00

Send Message Contact Supplier

Shandong Naxin New Energy Co., Ltd.

View Supplier

Registration Date October 2017

Number of Employees 200

Factory Area 46,000 m²

Annual Sales 400 Million RMB

Main Products Water Source Heat Pump, Air Source Heat Pump, Low Temperature Difference Waste Heat Recovery Unit, Filter, Micro-filter, Protein Separator, Oxygen Increasing Equipment, Disinfection Equipment, Aquaculture Pond, Intelligent Bait Feeder, Fish Manure Collector; Full Life Cycle System Solutions for Modern Agriculture & Aquaculture

Target Markets Aquaculture Industry, Industrial Recirculating Aquaculture System

Details

Specifications

The device uses Venturi jets to draw in air or ozone, forming fine bubbles that come into full contact with water in a spiral flow path. Through adsorption, oxidation and coagulation, proteins, organic matter and fine particles are captured and carried out with foam for purification. Made of corrosion-resistant materials with a simple, easy-to-operate design, it delivers stable removal efficiency of 60%-70% without compressed air, making it an efficient and energy-saving key equipment for aquaculture and water treatment.

Model

HXPS-1200 / HXPS-1500 / HXPS-1800 / HXPS-2200

Diameter (mm)

1200 / 1500 / 1800 / 2200

Height (mm)

2880 / 3200 / 3300 / 3720

Recommended Treatment Volume (m³/h)

100 / 150 / 200 / 300

Floor Space (m×m)

1.5×1.5 / 1.8×1.8 / 2.2×2.2 / 2.6×2.6

Circulating Pump Quantity

Pump Power (kW)
