The all-terrain tracked chassis solves the harvesting problem of wet hilly farmland
The wide and thick rubber track has a large ground contact area and a low ground pressure, which can prevent sinking and slipping on muddy, waterlogged, sloping, and scattered terraces. The turning radius is small, the small plot operation is flexible, which solves the key problem that the wheeled silage harvester cannot operate in the rainy season, and is very suitable for the rainy hilly farmland in Southeast Asia and Africa.
Dual-disk non-packing tube, low loss, high efficiency
The front double turntable cutting table, with crop divider, does not need to be lined up when harvesting tall and short crops, and the stubble is evenly left after cutting. The feeding channel is widened to avoid blockage and entanglement, and the harvesting loss rate is less than 10%, which maximizes the utilization of raw materials.
Integrated multi-process design, saving labor costs
One machine can automatically complete cutting, conveying, high-speed shredding, corn grain crushing, high-level unloading, continuous operation, and no need for manual assistance. The rotatable unloading pipe can adjust the height and angle, unload the silage directly into the transport trailer, and eliminate the labor of secondary transportation.
Three series of models suitable for farms of all sizes
Small 100-150HP model, suitable for small and medium-sized ranches, individual cooperatives; Medium-sized 180-220HP model, suitable for medium-sized silage feed processing plants; Large-scale 200-200HP models are suitable for large-scale breeding bases and large-scale silage plants, and customers can choose models according to their production scale.
Adjustable shredding length improves the quality of silage fermentation
The multi-speed cutting adjustment structure supports 10-50 mm free length switching, meeting the needs of different livestock breeding. Equipped with grain crushing rollers, the corn kernels are fully crushed, improving the digestion and nutrient absorption rate of cattle and sheep.
One-stop all-round export supporting services
① Each machine comes with a complete factory specification sheet, factory inspection report, and bilingual operation and maintenance manual;
② The whole machine is cleaned and protected, the head, exhaust pipe, and track are individually packaged, and the solid wood frame is reinforced by sea freight;
③ 24-hour online technical support in Chinese and English, bulk supply of engine filters, track rubber blocks, cutting blades, and seals, can be exported separately for replenishment;
④ One-stop service for customs declaration, certificate of origin, and commercial inspection documents.
Overall Dimensions
5150×2100×2900
Rated Power of Matched Engine
74/88
Matching engine horsepower
100/120
Rated Speed of Matched Engine
2200
Driving Mode
Hydraulic Drive
Feeding Mechanism Type
Feed Roller
Header Cutter Type
Disc Cutter
