Automobile Flattening Machine

Automobile flattening machine is special processing equipment for scrapped vehicles. It uses hydraulic system to generate strong pressure, crushes scrapped vehicles into small pieces/thin sheets, greatly reduces volume to facilitate transportation and storage. It can also assist in separating recyclable components, helping to achieve efficient recycling and utilization of waste cars.
$35000.00
Send Message Contact Supplier
Shandong Huacheng Bangwei Machinery Co., Ltd.

Shandong Huacheng Bangwei Machinery Co., Ltd.

View Supplier
Registration Date March 10, 2025
Number of Employees 100-150
Factory Area Above 2,000 m²
Annual Sales 60 Million RMB
Main Products Vertical Hydraulic Baler, Horizontal Hydraulic Baler, Metal Briquetting Machine, Sponge Compressor, Wrapping Machine, Hydraulic Shearing Machine, Shredder, Car Crushing Machine, Sand Fixing Machine, Cutting Machine
Target Markets Global Markets
Details
Specifications
This machine is large frame-type double-cylinder hydraulic flattening equipment, with PLC + remote dual control mode and air cooling system. High-pressure hydraulic power is stable and powerful. It can flatten various scrapped motor vehicles such as cars and vans into dense flat blocks at one time, greatly reducing storage, transportation and dismantling recycling costs. The whole machine is made of solid materials, matched with brand motor, oil pump and high-pressure oil pipe, stable and durable operation. Special large processing equipment for scrapped car recycling & dismantling plants.
Equipment Name
Automobile Flattening Machine
Model
400Type
Cylinder Stroke
1600mm
Oil Cylinder
350×1600×2 Double Cylinder, Cylinder Bore 351mm
Ram Pump
HY-160×2
Total Power
30kw×2
Motor Power
30kw×2
Oil Tank Capacity
1400L
Cooling System
Air Cooling
Working Pressure
≤20-30MPa
Overall Boundary Dimension
6200×2500×3700mm
Material Tray Size
5300×2500×1800mm
Control Mode
PLC + Remote Control
Power Specification
380V/PH, 50HZ
Motor Brand
Hebei Mengxiang
Hydraulic Oil Pump
Qidong Lishun
Electrical Components
Chint / Delixi
Oil Tube
4-layer Steel Wire High-pressure Oil Tube
Machine Weight
27Ton
Application
Scrapped Car Flattening, Recycling & Dismantling, Waste Vehicle Volume Reduction & Transportation
  • Automobile Flattening Machine
  • Automobile Flattening Machine
  • Automobile Flattening Machine
  • Automobile Flattening Machine
  • Automobile Flattening Machine
  • Automobile Flattening Machine

Description

This machine is large frame-type double-cylinder hydraulic flattening equipment, with PLC + remote dual control mode and air cooling system. High-pressure hydraulic power is stable and powerful. It can flatten various scrapped motor vehicles such as cars and vans into dense flat blocks at one time, greatly reducing storage, transportation and dismantling recycling costs. The whole machine is made of solid materials, matched with brand motor, oil pump and high-pressure oil pipe, stable and durable operation. Special large processing equipment for scrapped car recycling & dismantling plants.
